ApplicationÂ
VFFS packing machine with screw filler and screw feeder capable of packing non free flow type products like flour, coffee powder, chili powder, spice powder, soap powder, curry powder, washing powder, garlic powder, onion powder, protein powder, seasoning powder etc.
Parameters
| Model | QP-420 | QP-520 | QP-730 | QP-900 | QP-1080 | QP-1200 |
| Film Thickness | 0.04-0.12mm | 0.04-0.12mm | 0.04-0.12mm | 0.04-0.12mm | 0.04-0.12mm | 0.04-0.12mm |
| Bag Length | 80-300mm | 80-350mm | 100-500mm | 100-600mm | 100-800mm | 100-1000mm |
| Bag Width | 60-200mm | 100-250mm | 180-350mm | 260-430mm | 290-505mm | 290-580mm |
| Film Roll Diameter | Max.350mm | Max.350mm | Max.350mm | 400mm | 400mm | 400mm |
| Pakaging Rate | 5-60bag/min | 5-60bag/min | 5-60bag/min | 5-60bag/min | 5-60bag/min | 5-60bag/min |
| Film Width | Max.420mm | Max.520mm | Max.720mm | Max.900mm | Max.900mm | Max.1200mm |
Features
-
Multi language operation system with touch screen.
-
High quality PLC control, stable performance with simple setting on the screen.
-
With pre-set parameters storage function, capable of restore 99 sets of parameters, easy for changing products.
-
Independent temperature control system, make sure high accurate temperature for each kind of packaging materials.
-
With step motor driving the film delivery system, running smooth and stable.
-
High quality sealing set to ensure the bag sealing and cutting clean and good looking.
-
High automatic level, auto finishing al the steps of feeding, filing, bagging, date coding, etc.
-
Stainless steel 304 body material, stain proof, good for maintenance.
Sample bags
