Application
Flow packing machine is packaged in the form of flowing.It is suitale for products such as orange,apple,lemon,tomato,potato etc.
Features
-
Product description: Pillow packing machine is suitable for food industry, pharmaceutical industry, toy stationery, plastic products, industrial supplies, daily necessities, disposable products, hardware products, industrial parts, auto parts.
-
Performance characteristics
-
The bag length does not need to be manually set, and the equipment is automatically detected and set automatically during operation.
-
Three servo control, mechanical structure, easy maintenance, less wear and long life.
-
Touch screen display, good man-machine interface, intuitive and convenient operation.
-
The packaging speed and bag length are controlled by servo, stepless speed change, wide adjustment range, and can be matched with the previous process of the production line.
-
High-sensitivity photo eyes automatically and accurately track.
-
The temperature of each sealing is independently controlled, suitable for packaging of various materials, and the sealing is beautiful and firm.
Parameters
Model | QP-250 | QP-350 | QP-450 | QP-600 |
Film width | Max250mm | Max350mm | Max450mm | Max600mm |
Bag length | 65-190mm or120-280mm | 65-190mm or120-280mm | 150-450mm | 160-500mm |
Bag width | 30-110mm | 50-160mm | 50-180mm | 100-280mm |
Product height | Max.40mm | Max.40mm | Max.75mm | Max.110mm |
Film roll diameter | Max.320mm | |||
Packaging speed | 40-230 bags/min | 40-180bags/min | 30-150Bags/min | 20-150 bags/min |
Power | 220V,50/60Hz,2.4kw | 220V,50/60Hz,2.6kw | 220V,50/60Hz,2.8kw | 220V,50/60Hz,2.8kw |
Machine dimensions | 3770mm×720mm×1420mm | 4030×770×1420mm | 4030×820×1420mm | 4030×970×1500mm |
Machine weight | 500kg | 580kg | 650kg | 680kg |
Film material | OPP/ PE/ PVC/ OPP/ CPP/ PT/ PE/ KOP/ CPP/ Aluminum Coating Film/ Aluminum Film |
