Application
Automatic vertical packaging machine working with multi heads weigher, capable of packing different kinds of products like rice beans, puffed food, potato chips, coffee bean, crispy rice, jelly, candy, pistachios, vegetable salad, dumplings, glutinous rice balls, chocolate, pet food, hardware items, apple slices, banana chips, frozen food, medicines etc.
Parameters
| Model | QP-420 | QP-520 | QP-730 | QP-900 | QP-1080 | QP-1200 |
| Film Thickness | 0.04-0.12mm | 0.04-0.12mm | 0.04-0.12mm | 0.04-0.12mm | 0.04-0.12mm | 0.04-0.12mm |
| Bag Length | 80-300mm | 80-350mm | 100-500mm | 100-600mm | 100-800mm | 100-1000mm |
| Bag Width | 60-200mm | 100-250mm | 180-350mm | 260-430mm | 290-505mm | 290-580mm |
| Film Roll Diameter | Max.350mm | Max.350mm | Max.350mm | 400mm | 400mm | 400mm |
| Pakaging Rate | 5-60bag/min | 5-60bag/min | 5-60bag/min | 5-60bag/min | 5-60bag/min | 5-60bag/min |
| Film Width | Max.420mm | Max.520mm | Max.720mm | Max.900mm | Max.900mm | Max.1200mm |
Features
-
7 inches touch screen, multi language peration system easier for workers to operate the machine.
-
PLC control system, reliable performance and easy for parameters setting.
-
With a memory storage for pre-set parameters of different products, fast change products.
-
PID temperature controller, Accurate temperature control for various packing materials.
-
Film pulling system controlled by step motor, make film running more smooth.
-
Using double servo film-dragging structure, enable bag forming for perfect bag shape.
-
Sophisticated sealing set ensures bag sealing and cutting consistency.
-
Automatically finish the process of feeding, filling, bag forming, date printing, sealing.
-
Food grad stainless steel body material, clean and safe for food products.
